DS18 GEN-X6000.1D Class D 1-Channel Monoblock Amplifier 6000 Watts
DS18 GEN-X6000.1D Class D 1-Channel Monoblock Amplifier 6000 Watts
The DS18 GEN-X line was developed with the customer in mind. We wanted to produce the sturdiest amplifier possible within a reasonable price range, and after months of R&D, we finally put together the most attractive design with top of the line internal technologies. All internal parts are manufactured by DS18.
With their lower power consumption and high efficiency, the GEN-X amplifiers can be installed without the need of a secondary or high-output alternator.
Highlights
- Lightweight design that retains very high durability with incorporated high efficiency heat sync.
- High quality circuit board to give the most power with a high efficiency rate.
Technical Details
- RMS Power @ 14.4VDC
-
Power at 4 Ohm 700W
-
Power at 2 Ohm 1200W
-
Power at 1 Ohm 2000W
- THD Distortion 0.08%
- Low Pass Filter: 40HZ 180Hz
- Bass Boost: 0dB to +12dB
- Subsonic: 17Hz - 50Hz
- Bass Frequency: 30Hz - 80Hz
- MOSFET Class D Monoblock Amplifier
- Dimensions (L x W x H): 380 x 190 x 60 mm
