PS Shallow-Mount Water Resistant 10" Subwoofer | 500W RMS DVC 2-Ohm

Product image 1
1 / 6
+1

PS Shallow-Mount Water Resistant 10" Subwoofer | 500W RMS DVC 2-Ohm

DS18 PSW10.2D 10" Water Resistant Shallow Subwoofer 1000 Watts 2 OHM DVC

There’s always space for bass with the PSW10.2D!

The PSW10.2D mounts in depths as small as 3.5” and can be utilized in both ported and sealed boxes for great bass in a tight area. The high-quality push terminals on the PSW series subwoofers also make connection to your speaker wire and amp extremely easy.

This sub handles 500 W RMS and 1000 W MAX Power with a 84 dB sensitivity: high sensitivity for a shallow mount sub allowing this light subwoofer to reproduce heavy clear bass!

The PPI Molding on the cone used by the PSW10.2D is also water resistant, making this speaker perfect for your bike, off-road or marine vehicle. The steel basket gives this speaker even stronger resistance against shock and vibration.

This sub comes in 2 Ohms Dual Voice Coil configuration so if wired appropriately it’s insane power will bring all your music to life!

Highlights

  • DS18's PSW shallow subwoofer series are known for producing great bass without sacrificing much space.
  • Rubber surround design fortifies this subwoofer and helps it push out cleaner and clearer bass
  • Shallow mount size allows this sub to fit in compact places and requires less box space than other subs.
  • High 9.5mm Xmax which produces full and deep bass with the correct box spec.

Great For

  • Car Audio
  • Bike Audio
  • Marine Audio
  • Off-Road Audio
  • Powersports Audio

    Technical Details
                 Download PSW10.2D Product Manual


    SPECIFICATIONS
    Nominal Diameter  10” / 254 mm
    Nominal Impedance  2+2 Ohms
    RMS Power Handling  500 W
    MAX Power Handling  1000 W
    Sensitivity (1w/1m)  84 dB
    Frequency Response 20 - 800 Hz
    Recommended Lo Pass Crossover 90 Hz
    MOTOR
    Voice Coil Diameter 2.5" / 63.5 mm
    Voice Coil Former Material  Aluminum
    Winding Material  Copper
    Cone Material Water Resistant PPI
    Surround Material Rubber
    Basket Material  Steel
    Basket Color/Finish Matt Black
    Magnet Material Ferrite
    Magnet Weight 58 Oz
    Displacement Volume 0.8L / 0.028ft3
    RECOMMENDED ENCLOSURES
    Sealed Internal Volume 14.2L / 0.5ft3
    Sealed Box Output Response 44 Hz
    MEASUREMENT
    Overall Diameter 10.23" / 260 mm
    Overall Depth 3.6" / 92 mm
    Front Mount Baffle Cutout 9.2" / 234 mm
    Mounting Depth 3" / 78 mm
    Motor Diameter 6.5" / 165 mm

    DS18 PSW10.2D 10" Water Resistant Shallow Subwoofer 1000 Watts 2 OHM DVC

    There’s always space for bass with the PSW10.2D!

    The PSW10.2D mounts in depths as small as 3.5” and can be utilized in both ported and sealed boxes for great bass in a tight area. The high-quality push terminals on the PSW series subwoofers also make connection to your speaker wire and amp extremely easy.

    This sub handles 500 W RMS and 1000 W MAX Power with a 84 dB sensitivity: high sensitivity for a shallow mount sub allowing this light subwoofer to reproduce heavy clear bass!

    The PPI Molding on the cone used by the PSW10.2D is also water resistant, making this speaker perfect for your bike, off-road or marine vehicle. The steel basket gives this speaker even stronger resistance against shock and vibration.

    This sub comes in 2 Ohms Dual Voice Coil configuration so if wired appropriately it’s insane power will bring all your music to life!

    Highlights

    • DS18's PSW shallow subwoofer series are known for producing great bass without sacrificing much space.
    • Rubber surround design fortifies this subwoofer and helps it push out cleaner and clearer bass
    • Shallow mount size allows this sub to fit in compact places and requires less box space than other subs.
    • High 9.5mm Xmax which produces full and deep bass with the correct box spec.

    Great For

    • Car Audio
    • Bike Audio
    • Marine Audio
    • Off-Road Audio
    • Powersports Audio

      Technical Details
                   Download PSW10.2D Product Manual


      SPECIFICATIONS
      Nominal Diameter  10” / 254 mm
      Nominal Impedance  2+2 Ohms
      RMS Power Handling  500 W
      MAX Power Handling  1000 W
      Sensitivity (1w/1m)  84 dB
      Frequency Response 20 - 800 Hz
      Recommended Lo Pass Crossover 90 Hz
      MOTOR
      Voice Coil Diameter 2.5" / 63.5 mm
      Voice Coil Former Material  Aluminum
      Winding Material  Copper
      Cone Material Water Resistant PPI
      Surround Material Rubber
      Basket Material  Steel
      Basket Color/Finish Matt Black
      Magnet Material Ferrite
      Magnet Weight 58 Oz
      Displacement Volume 0.8L / 0.028ft3
      RECOMMENDED ENCLOSURES
      Sealed Internal Volume 14.2L / 0.5ft3
      Sealed Box Output Response 44 Hz
      MEASUREMENT
      Overall Diameter 10.23" / 260 mm
      Overall Depth 3.6" / 92 mm
      Front Mount Baffle Cutout 9.2" / 234 mm
      Mounting Depth 3" / 78 mm
      Motor Diameter 6.5" / 165 mm

      $179.95
